Azure AD Connect PowerShell Cmdlets

documentation

Click the image!

Microsoft TechNet used to be one of the best documentation libraries in the industry. Sadly, it still is; so what’s that tell you about the industry today?

Office 365 and Azure are truly great cloud services, but the frequency of updates and new releases are a challenge for Microsoft’s own sales team to keep up with, let alone us in the field, trying to work with the stuff. As made abundantly clear by their actions (e.g. killing tech conferences, technical writer layoffs, shuttering TechNet subscriptions, and abandoning the MCM program), Microsoft doesn’t really see “the problem”.

When Microsoft shipped DirSync and then later Azure AD Sync, documentation of the associated PowerShell modules became increasingly sparse, though some cmdlets did have a help synopsis, as I discussed last year. Azure AD Connect, the current version of Office 365 and Azure Active Directory synchronization technology, has 69 cmdlets in the “ADSync” module.

Wanna take a guess at how many of these have an associated help topic? Don’t forget, this product was launched earlier this summer and is now on it’s second public release.

Zero

(Pause for effect)

So, I have listed all 69 cmdlets here, with a brief note about what I’ve found so far. Right now, most are empty, but I will fill them in as I discover their purpose and/or have more time. If you’ve got a question about one I don’t have detailed, leave a comment and I’ll try to prioritize some research for you. I haven’t checked with the Azure AD team on this, so please take my findings with a grain of salt, and hope for real support documentation to arrive soon!

NOTE: This refers to the “ADSync” module that ships with Azure AD Connect 1.0.8667.0.

Cmdlet

Add-ADSyncAADServiceAccount

My
Comments

Sample
Usage



Cmdlet

Add-ADSyncAttributeFlowMapping

My
Comments

Maps a source to target
attribute.

Export one of the rules
from the editor to see this and other samples.

Sample
Usage

Add-ADSyncAttributeFlowMapping  `

-SynchronizationRule $syncRule[0] `

-Source @(‘mailNickname’,‘sAMAccountName’)
`

-Destination ‘cloudFiltered’
`

-FlowType ‘Expression’
`

-ValueMergeType ‘Update’ `

-Expression ‘IIF(IsPresent([isCriticalSystemObject])
|| IsPresent([sAMAccountName]) = False || [sAMAccountName] =
“SUPPORT_388945a0” || Left([mailNickname], 14) =
“SystemMailbox{” || Left([sAMAccountName], 4) = “AAD_” ||
(Left([mailNickname], 4) = “CAS_” && (InStr([mailNickname],
“}”) > 0)) || (Left([sAMAccountName], 4) = “CAS_”
&& (InStr([sAMAccountName], “}”) > 0)) ||
Left([sAMAccountName], 5) = “MSOL_” ||
CBool(IIF(IsPresent([msExchRecipientTypeDetails]),BitAnd([msExchRecipientTypeDetails],&H21C07000)
> 0,NULL)) ||
CBool(InStr(DNComponent(CRef([dn]),1),”\\0ACNF:”)>0), True,
NULL)’
`

-OutVariable syncRule

Cmdlet

Add-ADSyncConnector

My
Comments

Sample
Usage



Cmdlet

Add-ADSyncConnectorAnchorConstructionSettings

My
Comments

Sample
Usage





Cmdlet

Add-ADSyncConnectorAttributeInclusion

My
Comments

Sample
Usage





Cmdlet

Add-ADSyncConnectorHierarchyProvisioningMapping

My
Comments

Sample
Usage





Cmdlet

Add-ADSyncConnectorObjectInclusion

My
Comments

Sample
Usage



Cmdlet

Add-ADSyncGlobalSettingsParameter

My
Comments

Sample
Usage



Cmdlet

Add-ADSyncJoinConditionGroup

My
Comments

Used in the construction of
sync rules.

Export one of the rules
from the editor to see this and other samples.

Sample
Usage

Add-ADSyncJoinConditionGroup  `

-SynchronizationRule $syncRule[0] `

-JoinConditions @($condition0[0]) `

-OutVariable syncRule

Cmdlet

Add-ADSyncRule

My
Comments

Export one of the rules
from the editor to see this and other

samples.

Sample
Usage

Add-ADSyncRule  `

-SynchronizationRule $syncRule[0]

Cmdlet

Add-ADSyncRunProfile

My
Comments

Sample
Usage



Cmdlet

Add-ADSyncRunStep

My
Comments

Sample
Usage



Cmdlet

Add-ADSyncScopeConditionGroup

My
Comments

Used in the construction of
sync rules.

Export one of the rules
from the editor to see this and other samples.

Sample
Usage

Add-ADSyncScopeConditionGroup  `

-SynchronizationRule $syncRule[0] `

-ScopeConditions @($condition0[0],$condition1[0],$condition2[0]) `

-OutVariable syncRule

Cmdlet

Disable-ADSyncConnectorPartition

My
Comments

Sample
Usage



Cmdlet

Disable-ADSyncConnectorPartitionHierarchy

My
Comments

Sample
Usage



Cmdlet

Disable-ADSyncExportDeletionThreshold

My
Comments

 Disables the accidental deletion safety feature.

More info here: https://azure.microsoft.com/en-us/documentation/articles/active-directory-aadconnectsync-feature-prevent-accidental-deletes/

Sample
Usage

 Disable-ADSyncExportDeletionThreshold

Cmdlet

Enable-ADSyncConnectorPartition

My
Comments

Sample
Usage



Cmdlet

Enable-ADSyncConnectorPartitionHierarchy

My
Comments

Sample
Usage



Cmdlet

Enable-ADSyncExportDeletionThreshold

My
Comments

 Enables the accidental deletion safety feature. To verify, run Get-MsolDirSyncConfiguration.More info here: https://azure.microsoft.com/en-us/documentation/articles/active-directory-aadconnectsync-feature-prevent-accidental-deletes/

Sample
Usage

Enable-ADSyncExportDeletionThreshold

Cmdlet

Get-ADSyncAADPasswordResetConfiguration

My
Comments

I believe this is used to
report on password write-back.

Sample
Usage

Get-ADSyncAADPasswordResetConfiguration -Connector ‘demo1923.onmicrosoft.com – AAD’



Cmdlet

Get-ADSyncAADPasswordSyncConfiguration

My
Comments

Indicates whether or not
password hash sync is enabled (SYNC)

Sample
Usage

Get-ADSyncAADPasswordSyncConfiguration -SourceConnector ‘laptop.lab’

Cmdlet

Get-ADSyncConnector

My
Comments

Gets the management agents
(connectors) used by the sync service.

Sample
Usage

Get-ADSyncConnector

Cmdlet

Get-ADSyncConnectorHierarchyProvisioningDNComponent

My
Comments

Couldn’t get it to work

Sample
Usage

x =
Get-ADSyncConnector -Name
‘laptop.lab’

Get-ADSyncConnectorHierarchyProvisioningDNComponent -ShowHidden -Connector $x

Cmdlet

Get-ADSyncConnectorHierarchyProvisioningMapping

My
Comments

Couldn’t get it to work

Sample
Usage

$x =
Get-ADSyncConnector -Name
‘laptop.lab’

Get-ADSyncConnectorHierarchyProvisioningMapping -Connector $x

Cmdlet

Get-ADSyncConnectorHierarchyProvisioningObjectClass

My
Comments

Didn’t test: I presume it
lists the objects to be synced (e.g. people, contacts, etc)

Sample
Usage





Cmdlet

Get-ADSyncConnectorParameter

My
Comments

Sample
Usage



Cmdlet

Get-ADSyncConnectorPartition

My
Comments

Sample
Usage



Cmdlet

Get-ADSyncConnectorPartitionHierarchy

My
Comments

Sample
Usage



Cmdlet

Get-ADSyncConnectorTypes

My
Comments

Sample
Usage



Cmdlet

Get-ADSyncGlobalSettings

My
Comments

Displays Global
Configuration Settings.

Sample
Usage

  (Get-ADSyncGlobalSettings).Parameters
| Where name -eq Microsoft.SynchronizationOption.AnchorAttribute

Cmdlet

Get-ADSyncGlobalSettingsParameter

My
Comments

Sample
Usage



Cmdlet

Get-ADSyncRule

My
Comments

 Lists the sync rules

Sample
Usage



Cmdlet

Get-ADSyncRunProfile

My
Comments

Sample
Usage



Cmdlet

Get-ADSyncSchema

My
Comments

Sample
Usage





Cmdlet

Get-ADSyncServerConfiguration

My
Comments

Sample
Usage



Cmdlet

New-ADSyncConnector

My
Comments

Sample
Usage



Cmdlet

New-ADSyncJoinCondition

My
Comments

Sample
Usage



Cmdlet

New-ADSyncRule

My
Comments

Export one of the rules
from the editor to see this and other samples.

Sample
Usage

New-ADSyncRule  `

-Name ‘In from
AD – User Join’
`

-Identifier ‘c2db05cb-39bd-4e17-a19a-26718c692e48’
`

-Description
`

-Direction ‘Inbound’
`

-Precedence 100
`

-PrecedenceAfter ‘00000000-0000-0000-0000-000000000000’ `

-PrecedenceBefore ‘00000000-0000-0000-0000-000000000000’ `

-SourceObjectType ‘user’ `

-TargetObjectType ‘person’ `

-Connector ‘43617e64-d544-4426-9354-e7d7508915b1’
`

-LinkType ‘Provision’
`

-SoftDeleteExpiryInterval 0 `

-ImmutableTag ‘Microsoft.InfromADUserJoin.003’ `

-OutVariable syncRule

Cmdlet

New-ADSyncRunProfile

My
Comments

Sample
Usage



Cmdlet

New-ADSyncScopeCondition

My
Comments

Sample
Usage



Cmdlet

Remove-ADSyncAADPasswordResetConfiguration

My
Comments

Sample
Usage



Cmdlet

Remove-ADSyncAADPasswordSyncConfiguration

My
Comments

Sample
Usage



Cmdlet

Remove-ADSyncAADServiceAccount

My
Comments

Sample
Usage



Cmdlet

Remove-ADSyncAttributeFlowMapping

My
Comments

Sample
Usage



Cmdlet

Remove-ADSyncConnector

My
Comments

 Removes one of your Management Agents (Connectors)

Sample
Usage



Cmdlet

Remove-ADSyncConnectorAnchorConstructionSettings

My
Comments

Sample
Usage



Cmdlet

Remove-ADSyncConnectorAttributeInclusion

My
Comments

Sample
Usage



Cmdlet

Remove-ADSyncConnectorHierarchyProvisioningMapping

My
Comments

Sample
Usage





Cmdlet

Remove-ADSyncConnectorObjectInclusion

My
Comments

Sample
Usage



Cmdlet

Remove-ADSyncGlobalSettingsParameter

My
Comments

Sample
Usage



Cmdlet

Remove-ADSyncJoinConditionGroup

My
Comments

Sample
Usage



Cmdlet

Remove-ADSyncRule

My
Comments

 Removes a sync rule.

Sample
Usage



Cmdlet

Remove-ADSyncRunProfile

My
Comments

Sample
Usage



Cmdlet

Remove-ADSyncRunStep

My
Comments

Sample
Usage



Cmdlet

Remove-ADSyncScopeConditionGroup

My
Comments

Sample
Usage



Cmdlet

Search-ADSyncDirectoryObjects

My
Comments

Sample
Usage



Cmdlet

Set-ADSyncAADCompanyFeature

My
Comments

Sample
Usage



Cmdlet

Set-ADSyncAADPasswordResetConfiguration

My
Comments

Sample
Usage



Cmdlet

Set-ADSyncAADPasswordSyncConfiguration

My
Comments

 See details here:  http://blogs.technet.com/b/undocumentedfeatures/archive/2015/11/18/reset-aadsync-or-aadconnect-password-hash-sync-configuration.aspx

Sample
Usage

Set-ADSyncAADPasswordSyncConfiguration -SourceConnector $adConnector -TargetConnector $aadConnector -Enable $false

Cmdlet

Set-ADSyncAADPasswordSyncState

My
Comments

Sample
Usage



Cmdlet

Set-ADSyncConnectorParameter

My
Comments

Sample
Usage



Cmdlet

Set-ADSyncGlobalSettings

My
Comments

Sample
Usage



Cmdlet

Set-ADSyncSchema

My
Comments

Sample
Usage



Cmdlet

Set-ADSyncServerConfiguration

My
Comments

Sample
Usage



Cmdlet

Set-MIISADMAConfiguration

My
Comments

Sample
Usage



Cmdlet

Test-AdSyncUserHasPermissions

My
Comments

Sample
Usage



Cmdlet

Update-ADSyncConnectorPartition

My
Comments

Sample
Usage



Cmdlet

Update-ADSyncConnectorSchema

My
Comments

Sample
Usage



Cmdlet

Update-ADSyncDRSCertificates

My
Comments

Sample
Usage
